T82 Technical data
35
Filter 1st order digital filter: 0 to 120 s
Current consumption • 3.6 to 23 mA
• Minimum current consumption ≤ 3.5 mA
• Current limit ≤ 23 mA
Protocol-specific data
HART ® version 6
Device address in multi-drop mode Software setting addresses 0 to 63
Write protection Hardware setting for activating write protection
Device description files (DD) Information and files are available from your supplier or online at:
www.hartcomm.org
Load (communication resistor) min. 250 W
Switch-on delay 5 s, during switch-on delay I
a
£ 3.8 mA
12.3 Power supply
Supply voltage U = 11 to 42 V DC (non-hazardous area), reverse polarity protected. Values for hazardous area
see chapter 'Certificates and approvals' (® ä 39).
Residual ripple Perm. residual ripple U
ss
≤ 3 V at U
b
≥ 13.5 V, f
max.
= 1 kHz
12.4 Performance characteristics
Response time Measured value update < 1 s per channel, depending on the type of sensor and connection
method
Reference operating
conditions • Calibration temperature: +25 °C ±5 K (77 °F ±9 °F)
• Supply voltage: 24 V DC
• 4-wire circuit for resistance adjustment
Maximum measured error The accuracy data are typical values and correspond to a standard deviation of ±3 s (normal
distribution), i.e. 99.8 % of all the measured values achieve the given values or better values.
Designation/measuring range Performance characteristics
Digital D/A 1)
Resistance
thermometer (RTD) Pt100, Ni100, Ni120
Pt500
Cu50, Pt50, Pt1000
Pt200 0.1 °C (0.18 °F)
0.3 °C (0.54 °F)
0.2 °C (0.36 °F)
1.0 °C (1.8 °F) 0.03 %
0.03 %
0.03 %
0.03 %
Thermocouples (TC) Type: K, J, T, E, L, U
Type: N, C, D
Type: S, B, R
0.25 °C (0.45 °F)
0.5 °C (0.9 °F)
1.0 °C (1.8 °F) 0.03 %
0.03 %
0.03 %
