Diagnostics and troubleshooting

T82

Problem

Possible cause

Remedy

The cable resistance of the sensor (2-
wire) was not compensated.

Compensate the cable resistance.

Offset incorrectly set.

Check offset.

Failure current (≤ 3.6 mA or
≥ 21 mA)

Faulty sensor.

Check the sensor.

RTD connected incorrectly.

Connect the connecting cables correctly
(terminal diagram).

Incorrect device programming (e.g.
number of wires).

Change the Connection type device
function.

Incorrect programming.

Incorrect sensor type set in the Sensor
type device function. Set the correct sensor
type.

Application errors without status messages for TC sensor connection

Problem

Possible cause

Remedy

Measured value is incorrect/
inaccurate

Incorrect sensor orientation.

Install the sensor correctly.

Heat conducted by sensor.

Observe face-to-face length of the sensor.

Device programming is incorrect
(scaling).

Change scaling.

Incorrect thermocouple type (TC)
configured.

Change the Sensor type device function.

Incorrect comparison measuring point
set.

Set the correct reference junction
(® ä 52).

Interference via the thermocouple wire
welded in the thermowell (interference
voltage coupling).

Use a sensor where the thermocouple wire
is not welded.
