KROHNE IFC 210 E-EEx EN User Manual
Page 33
Part B IFC 210 Signal converter Sect. 4.4
05/2002
IFC 210 E
33
Fct.
Display-Texts
Description and settings
1.0_ Controlinput
Set
as
Control
input
B1
and/or B2
• Off (switched off)
• Ext.Range (external range change)
Press
↵
key to transfer to number setting.
Setting range: 05 - 80% (= ratio of lower to upper range from
1:20 to 1:1.25. Value must be greater than that of Fct. 1.03 L.F. CUTOFF).
• Outp.Hold
(hold value of outputs)
• Outp.Zero
(set outputs to min.values)
• Total. Reset
(reset totalizers)
• Error. Reset
(delete error messages)
Press
↵
key to return to Fct. 1.07 a
nd/or 1.08 “
Statusoutput”
Fct.
Display-Texts
Description and settings
2.00
Test
Test menu
2.01
Test Q
Test measuring range Q
Precautionary query
• SURE NO
Press
↵
key to return to Fct. 2.01 TEST Q .
• SURE YES
Press
→
key to transfer to number setting.
select value: -110 / -100 / -50 / -10 / 0 / +10 / +50 / +100 / +110 PCT..
of set full-scale range Q
100%
.
Displayed value present at outputs I and P.
Press
↵
key to return to Fct. 2.01 “TEST Q” .
2.02
Hardwareinfo
Hardware information and error status
Before consulting factory, please note down all codes.
Modul
ADC
X . X X X X X . X X
Y Y Y Y Y Y Y Y Y Y
Modul
IO
X . X X X X X . X X
Y Y Y Y Y Y Y Y Y Y
Press
↵
key to transfer to next info.
Modul
DISP.. X . X X X X X . X X
Y Y Y Y Y Y Y Y Y Y
Modul
RS
X . X X X X X . X X
(only provided if “computer interface”
Y Y Y Y Y Y Y Y Y Y
Option installed)
Press
↵
key to return to Fct. 2.02 “Hardwareinfo”.
2.03
Test Display
Press
→
key to start test of display, duration approx. 5 sec.
Fct.
Display-Texts
Description and settings
3.00
Installation
Installation menu
3.01
Language
Select language for display texts
• GB / USA (English)
• F (French)
• D (German)
• others on request
Press
↵
key to return to Fct. 3.01 “Language”.
3.02
Flowmeter
Set data for primary head
Diameter
Select size from meter size table
• DN 2.5 - 3000 mm equivalent to
1
/
10
– 120 inch
Select with
↑
key.
Press
↵
key to transfer to subfunction “Full Scale”.
Full Scale
Full-scale range for flow Q
100%
Selection unit: •
m
3
/hr
• Liter/Sec
• US Gal/min
user unit, factory set is Liter/hr or US MGal/day (see Fct. 3.05)
Press
→
key to transfer to number setting.
Setting ranges:
The ranges are dependent on the meter size (DN) and the
flow velocity (v):
Q
min
= DN
2
x v
min
Q
max
= DN
2
x v
max
Nom. dia. /meter size
V
min
= 0,3 m/s (1 ft/s) V
max
= 12 m/s (40 ft/s)
• DN 2.5–1600 /
1
/
10
– 64:
0.0053 –
86 859 m
3
/hr
0.0237 –
401 080 US Gal/min
Press
↵
key to transfer to subfunction “Gk Value”.
