Part B IFC 210 Signal converter Sect. 4.3
05/2002 IFC 210 E 27
4.3 Function of keys
The cursor has a grey background in the following descriptions.
To start operator control
m 3
– 298
hr
→
Σ
+00000.00
3.00 Installation
2.00 Test
m
3
1.00 Operation
Σ
–05632.01
PLEASE NOTE: When “yes” is set under Fct. 3.04 Entry Code,
„Code“ appears in the display after pressing the
→
key.
The 9-keystroke Entry Code 1 must now be entered:
→ → → ↵ ↵ ↵ ↑ ↑ ↑
(each keystroke acknowledged by “*”).
To select a function
Increase number
1.06 Pulsoutput P 1.06 Pulsoutput P
1.05 Currentoutput I
↑
1.05 Currentoutput I I
1.04 Display 1.04 Display
1.03 Low Flow Cutoff 1.03 Low Flow Cutoff
1.02 Timeconstant 1.02 Timeconstant
1.01 Full Scale
↓
1.01 Full Scale
Decrease number
To select a subfunction
1.06 Pulsoutput P Function:
1.05 Currentoutput I
→
1 Direction
1.04 Display Range I:
1.03 Low Flow Cutoff 00 – 20 mA
1.02 Timeconstant I Max:
1.01 Full Scale 20.5 mA
To alter texts
select next text
Function: Function:
1 Direction
↑
2 Directions
Range I: Range I:
00 – 20 mA 00 – 20 mA
I Max: I Max:
20.5 mA
↓
20.5 mA
select preceding text
