KROHNE IFC 210 E-EEx EN - Manual

Installation and
operating instructions
IFC 210 E
IFC 210 E-EEx
Signal converters for
electromagnetic flowmeters
Applicable to
Software Versions
● Operating and check elements
No. 3.18393.01
● Amplifier (ADC)
No. 3.17116.01
● Outputs/inputs (I/O)
No. 3.19005.01
How to use these Instructions
The flowmeters are supplied ready for operation.
The primary head must be installed in the pipeline as described in the installation
instructions inside the packing of the primary head.
– Installation location and connection to power (Section 1) Pages 6-15
– Electrical connection of outputs and inputs (Section 2) Pages 16-22
– Factory settings and start-up (Section 3) Pages 23
Power the flowmeter. THAT’S ALL. The system is operative.
Pull-out
Condensed Instr
uctions
Variable area flowmeters
Vortex flowmeters
Flow controllers
Electromagnetic flowmeters
Ultrasonic flowmeters
Mass flowmeters
Level measuring instruments
Communications technology
Engineering systems & solutions
Switches, counters, displays and recorders
Heat metering
Pressure and temperature
DIN A4: 7.10006.31.00
© KROHNE 05/2002 US size: 7.10006.71.00
