Part B IFC 210 Signal converter Sect. 4.4
05/2002 IFC 210 E 31
Fct. Display-Texts Description and settings
1.04 DISPLAY Display functions
Contrast Set display contrast
• range from + 15 (high contrast) to - 15 (low contrast)
Press ↵ key to transfer to subfunction “Flow”.
Flow Set format for flow rate display
• #### • ### . # • ## . ## • # . #### • Auto
Press key → to move to unit selection.
Selection unit: • m 3 /hr • Liter/Sec • US Gal/min
user unit, factory set is Liter/hr or US MGal/day (see Fct. 3.05)
Press ↵ key to transfer to subfunction “Totalizer”.
Totalizer Set format for display of volume
Select decimal positions:
• ####### • ###### . # • ##### . ## • #### . ###
• ### . #### • ## . ##### • # . ###### • Auto
Press
→
key to move to unit selection.
• m 3 • Liter • US Gal
user unit, factory set is Liter or US MGal (see Fct. 3.05)
Press ↵ key to transfer to subfunction “Messages”.
Messages Additional displays wanted in measuring mode?
• no • yes (overlay additional messages)
Press ↵ key to transfer to subfunction “Trend”.
Trend Set graphic display
Selection: • Average (show average values over time base)
• Min. & Max. (min./max. values over time base)
• Every Value (all values numbered consecutively)
Press
↵
key to transfer to subfunction “Updating”.
When “every value“ selected, transfer to subfunction “Scaling“.
Updating Update measured values in graphic display
(this not shown when “every value“, see above, selected)
Selection: • 0.1 Sec. • 0.2 Sec. • 0.5 Sec. • 1 Sec.
• 2 Sec. • 5 Sek. • 1 Min. • 2 Min. • 5 Min.
Press
↵
key to transfer to subfunction “Scaling”.
Scaling Set scaling of graphic display
Selection: • 0% ... 100% • - 25% ... 100%
• 0% ... 50% • 50% ... 100%
• -100% ... 0% • 25% ... -100%
• - 50% ... 0% • -100% ... - 50%
• Auto
Press
↵
key to return to Fct. 1.04 DISPLAY.
1.05 Current output I Set Current output I
Function Set Function
• Off (switched off)
• 1 Direction (1 flow direction)
• 2 Directions (forward/reverse flow, F/R flow measurement)
Press
↵
key to transfer to subfunction “Range I”.
Range I Set measuring range (I
0%
... I
100%
)
• 0 - 20 mA • 4 - 20 mA (fixed ranges))
• mA (user-defined range)
• Range: I
0%
- I
100%
(Value I
0%
< I
100%
!) 0 - 16 mA 4 - 20 mA
Press → key to transfer to number setting.
Press
↵
key to transfer to subfunction “I Max”.
I Max Set I Max
Selection: • 20,5 mA • 22 mA
Press
↵
key to transfer to subfunction “I Error”.
