8
TECHNICAL DATA
78
IFC 100
www.krohne.com 07/2010 - 4000041004 - MA IFC 100 R04 en
Display and user interface Display and user interface Display and user interface Display and user interface
Graphic display LC display, backlit white.
Size: 128 x 64 pixels, corresponds to 59 x 31 mm = 2.32" x 1.22"
Ambient temperatures below -25°C / -13°F, may affect the readability of the display.
Operating elements 4 push buttons for operator control of the signal converter without opening the
housing.
Remote control PACTware ® (incl. Device Type Manager (DTM)) (in preparation)
HART ® Hand Held Communicator from Emerson Process (in preparation)
AMS ® from Emerson Process (in preparation)
PDM ® from Siemens (in preparation)
All DTMs and drivers are available free of charge from the manufacturer's website.
Display functions Display functions Display functions Display functions
Operating menu Setting the parameters using 2 measured value pages, 1 status page, 1 graphics
page (measured values and graphics are freely adjustable)
Language display texts English, French, German, Dutch, Polish, Portuguese, Danish, Spanish, Swedish,
Slovenian, Italian (others on request)
Units Metric, British and US units selectable as required from lists for volume / mass flow
and counting, flow velocity, electrical conductivity, temperature
Measuring accuracy
Reference conditions Medium: water
Temperature: 20°C / 68°F
Pressure: 1 bar / 14.5 psi
Inlet section: ≥ 5 DN
Maximum measuring error ± 0.3% of the measured value ±1 mm/s, depending on the measuring sensor
For detailed information and accuracy curves, refer to chapter "Accuracy".
Repeatability ± 0.1%
