Electrical connections – KROHNE IFC 100 Converter EN User Manual
Page 28
4
ELECTRICAL CONNECTIONS
28
IFC 100
www.krohne.com
07/2010 - 4000041004 - MA IFC 100 R04 en
4.5.1 Connecting the signal and field current cables to the signal converter, remote
version
Open housing
1 Loosen the 4 screws with a suitable tool.
2 Lift the housing at the top and bottom at the same time.
3 Slide the housing cover upward.
4 The housing cover is guided and held by the inside hinge.
INFORMATION!
The compact version is supplied preassembled from the factory.
Figure 4-7: Open housing
.book Page 28 Friday, July 9, 2010 12:29 PM
