KROHNE IFC 100 Converter EN - Manual (Page 65)

OPERATION
6
65
IFC 100
www.krohne.com 07/2010 - 4000041004 - MA IFC 100 R04 en
C5.2 display
C5.2 display -
C5.2.1 language Language selection depends on the device version.
C5.2.2 contrast Adjust display contrast for extreme temperatures.
Setting: -9…0…+9
This change takes place immediately, not just when setting mode is exited!
C5.2.3 default display Specification of the default display page that is returned to after a short
delay period.
Select:
none (the current page is always active) / 1. meas. page (show this page) /
2. meas. page (show this page) / status page (show only status messages) /
graphic page (trend display of the 1st measurement)
C5.2.5 SW.REV.UIS Serial no. of the circuit board, version no. of user software, production date
of the circuit board
C5.3 & C5.4 1. meas. page & 2. meas. page
C5.3 1. meas. page stands for 3 = meas. page 1 and 4 = meas. page 2
C5.4 2. meas. page
C5. .1 function Specify number of measured value lines (font size)
Select: one line / two lines / three lines
C5. .2 measurement 1.line Specify measurement for 1st line.
Select: volume flow / mass flow / diagnosis value / flow speed / coil
temperature / conductivity
C5. .3 range 0…100% of the measurement set in Fct. C5. .2
0…xx.xx _ _ _ (format and unit depend on the measurement)
C5. .4 limitation Limitation before applying the time constant.
xxx%; range: -120…+120%
C5. .5 low flow cutoff Sets output to "0": x.xxx ± x.xxx %; range: 0.0…20%
(1st value = switching point / 2nd value = hysteresis),
condition: 2nd value ≤ 1st value
C5. .6 time constant Range: 000.1…100 s
C5. .7 format 1.line Specify decimal places.
Select: automatic (adaptation carried out automatically) /
X (= none) …X.XXXXXXXX (max. 8 digits)
C5. .8 measurement 2.line Specify measurement 2.line (only available if this 2.line is activated)
Select: bar graph (for the measurement selected in 1.line) / volume flow /
mass flow / diagnosis value / flow speed / counter 1 / counter 2 / conductivity
/ coil temperature / operating hours
C5. .9 format 2.line Specify position after decimal point (only available if this 2.line is activated)
Select: automatic (adaptation carried out automatically) /
X (= none) …X.XXXXXXXX (max. 8 digits)
C5. .10 measurement 3.line Specify measurement 3.line (only available if this 3.line is activated)
Select: volume flow / mass flow / diagnosis value / flow speed / coil
temperature / conductivity / counter 1 / counter 2 / operating hours
C5. .11 format 3.line Specify position after decimal point (only available if this 3.line is activated)
Select: automatic (adaptation carried out automatically) /
X (= none) …X.XXXXXXXX (max. 8 digits)
