DESCRIPTION OF HART INTERFACE
110
IFC 100
www.krohne.com 07/2010 - 4000041004 - MA IFC 100 R04 en
9.12 Appendix C: HART ® menu tree for PDM
Abbreviations of the following tables:
• Opt Optional, depending on device version and configuration
• Rd Read only
• Cust Custody lock protection
• Loc Local PDM, affects only PDM views
9.12.1 Overview PDM menu tree (positions in menu tree)
Overview: Menu Device
Overview: Menu View
Communication Path
Load To Device
Load To PG/PC
Set Address
Test
Reset
Calibration
HART
Display Display
Totalizer
Yt diagram
Outputs Current output A Opt
Frequency output D Opt
Device Status Device
HART
Standard (overview)
Failure (device)
Failure (application)
Out of specification
Check request
Information
Circuit board info
Toolbar
Status Bar
Update
