OPERATION
50
IFC 100
www.krohne.com 07/2010 - 4000041004 - MA IFC 100 R04 en
Measuring mode Select
menu ↓
↑
Select menu and/or sub-menu
↓ ↑
Select
function
and set
data
↓ ↑ >
^ Press
> 2.5 s
C setup >
^
C1 process input >
^
1.1 calibration >
^
1.2 filter
1.3 self test
1.4 information
1.5 simulation
^ >
^
C2 I/O (Input/Output) >
^
2.1 hardware >
^
2. current output X
2. frequency output X
2. pulse output X
2. status output X
2. limit switch X
^ >
^
C3 I/O counter >
^
3.1 counter 1 >
^
3.2 counter 2
^ >
^
C4 I/O HART >
^
4.1 PV is >
^
4.2 SV is
4.3 TV is
4.4 4V is
4.5 HART units
^ >
^
C5 device >
^
5.1 device info >
^
5.2 display
5.3 1. meas. page
5.4 2. meas. page
5.5 graphic page
5.6 special function
5.7 units
5.8 HART
5.9 quick setup
↓ ↑ ↓ ↑ ↓ ↑ ↓ ↑ >
