BOP-1K-GL 022814
1-7
FUNCTION GENERATOR CHARACTERISTICS (Continued)
Basic waveform parameters Sine: Frequency (Hz), Amplitude (Vp-p or Ap-p), Offset (Vd-c or Ad-c),
Start Phase (°), Stop Phase (°).
Triangular: Frequency (Hz), Amplitude (Vp-p or Ap-p), Offset (Vd-c or Ad-c), Start
Phase (°), Stop Phase (°).
Ramp (Pos. or Neg.): Frequency (Hz), Amplitude (Vp-p or Ap-p),
Offset (Vd-c or Ad-c).
Square: Frequency (Hz), Amplitude (Vp-p or Ap-p), Offset (Vd-c or Ad-c).
Level: Timing (sec), Amplitude (Vd-c or Ad-c).
• The start/stop phases are global parameters, applicable to all sine/ triangular
waveform segments. They are independent and can have any value between 0°
and 360°.
LIST command characteristics for “string” type
waveform Maximum number of points
• For single (global) dwell time:
5900 (high resolution)
• For <126 different dwell times:
3933
• For >126 different dwell times:
2950
Dwell time range: 93usec to 34msec.
Dwell time resolution (increment):
0.751usec
Skip feature (a number of steps can
be skipped from the LIST at the first
run using LIST:COUN:SKIP.)
Able to synchronize a LIST command
with multiple BOP’s or other devices
using Trigger Port (see Table 2-4
NOTE).
Able to sample output voltage or cur-
rent during LIST command execu-
tion (see Figures B-2 and B-3).
Note: Dwell time list must match (balance) the
amplitude list.
Frequency: Not applicable to Level
Range (Hz) 0.01 to 443 Sine, Triangle
0.02 to 532 ±Ramp
0.02 to 1000 Square
Programming Resolution (Hz) 0.01
Accuracy 1.5% of Frequency Sine, Triangle, Square, ±Ramp
Period (applicable to Level only)
Range (Seconds): 0.0005 TO 5.0000
Resolution: 0.0001
Accuracy: 1.5% of Time Duration
TABLE 1-2. BOP GENERAL SPECIFICATIONS (Continued)
SPECIFICATION RATING/DESCRIPTION CONDITION
