4-2
BOP-1K-GL 022814
EXTERNAL
CONTROLS,
SERIES 1. ZERO
2. POSITIVE External:
1. 0.0V
2. -10.0V
(Par/Ser CTRL-IN
Port, pin 8 ref to
COM S) Output Voltage:
1. 0.0V
2. +10.0V No Load
Automatic VM 1. DVM between OUT S
and COM S
2. Adjust for zero,
+10.0V
3. Calibrate unit for
Slave in Series
CURRENT,
INTERNAL 1. ZERO
2. POSITIVE
3. NEGATIVE Internal Output Current:
1. 0.0A
2. +Current FS
3. –Current FS Short with Meas.
Shunt
Automatic CM 1. DVM between probe
terminals of Meas.
Shunt (LO towards
COM S)
2. Adjust for zero, posi-
tive and negative FS.
3. Digital readback cali-
bration is done auto-
matically.
CURRENT,
PROTECTION 1. POSITIVE
2. NEGATIVE Internal Output Current:
1. +Current FS
2. -Current FS Short with Meas.
Shunt
Automatic VM 1. DVM between probe
terminals of Meas.
Shunt (LO towards
COM S)
2. Adjust for positive
and negative FS.
CURRENT,
EXTERNAL 1. ZERO
2. POSITIVE External:
1. 0.0V
2. +10.0V
(Analog I/O Port
pin 11 ref to 10) Output Current:
1. 0.0A
2. +Current FS Short with Meas.
Shunt
Automatic CM 1. DVM between probe
terminals of Meas.
Shunt (LO towards
COM S).
2)Adjust for zero, pos
FS.
CURRENT,
GAIN 1. ZERO
2. POSITIVE External:
1. 0.0V
2. +10.0V
(Analog I/O Port
pin 11 ref to 10) Output Current:
1. 0.0A
2. 0.0A Short with Meas.
Shunt
Automatic CM 1. DVM between probe
terminals of Meas.
Shunt (LO towards
COM S)
2. Adjust for zero
(both Zero and Positive)
EXTERNAL
CONTROLS,
PARALLEL 1. ZERO
2. POSITIVE External:
1. 0.0V
2. +10.0V
(Par/Ser CTRL-IN
Port pin3 ref. to
pin1) Output Current:
1. 0.0A
2. +Current FS Short with Meas.
Shunt
Automatic CM 1. DVM between probe
terminals of Meas.
Shunt (LO towards
COM S)
2. Adjust for zero, pos.
FS
3. Calibrate unit for
Slave in Parallel
EXTERNAL
CONTROLS,
I_OUT 1. ZERO
2. POSITIVE INTERNAL Voltage at Par/Ser
CTRL-IN Port pin 6
ref. to pin1:
1. 0.0V
2. +10.0V Short with Meas.
Shunt
Automatic CM 1. DVM at Par/Ser
CTRL-IN Port pin 6 ref.
to pin 1
2. Adjust for zero,
+10.0V
3. Calibrate unit for
Master in Parallel
EXTERNAL
PROTECTION,
Pos. Voltage
Neg. Voltage
Pos. Current
Neg. Current
(together) 1. ZERO
2. FULL
SCALE External:
1. 0.0V
2. +10.0V
(Analog I/O Port
pins 14, 6, 13, 5 ref
to pin12) N/A No requirements 1. Automatic internal
measurement
TABLE 4-1. CALIBRATION SUMMARY (CONTINUED)
Type Step
Reference Type and
Value
Monitored Parameter Output Conditions Notes
