GDS-800 Series Digital Storage Oscilloscope Operation Manual
74
Sensitivity
DC ~ 25MHz Approx. 0.5div or 5mV
25MHz ~ 60MHz Approx. 1.5div or 15mV for GDS-
806S/C
25MHz ~ 100MHz Approx. 1.5div or 15mV for GDS-
810S/C
25MHz ~ 150MHz Approx. 1.5div or 15mV for GDS-
820S/C and GDS-840S/C
150MHz ~ 250MHz Approx. 2div or 20mV for GDS-
840S/C
TV TV trigger sensitivity: 0.5 division of
synch signal
External Trigger：
Range DC：±15V，AC：±2V
Sensitivity
DC ~ 25MHz ~ 50mV for GDS-806S/C and GDS-
810S/C
DC ~ 30MHz ~ 50mV for GDS-820S/C and GDS-
840S/C
25MHz~60MHz ~100mV for GDS-806S/C
25MHz~100MHz ~100mV for GDS-810S/C
30MHz ~ 150MHz ~ 100mV for GDS-820S/C and GDS-
840S/C
150MHz ~ 250MHz ~ 150mV for GDS-840S/C
Input Impedance 1MΩ ±2﹪, ~ 18pF for GDS-806S/C,
GDS-810S/C, and GDS-840S/C;
1MΩ ±2﹪~22pF for GDS-820S/C
Maximum Input 300V (DC＋AC peak), CATII
