GDS-800 Series Digital Storage Oscilloscope Operation Manual
73
Polarity Normal & Invert
Maximum Voltage Between Signal and
Common at input BNC
300V (DC＋AC peak),
Installation Category II
Waveform Signal Process CH1－CH2、CH1＋CH2、FFT
Offset Range:
2mV/div ~ 50mV/div ±0.5V
100mV/div ~ 500mV/div ±5V
1V/div ~ 5V/div ±50V
Bandwidth Limit 20MHz (－3dB)
Trigger：
Sources CH1、CH2、LINE、EXT.
Modes Auto-Level、AUTO、NORMAL、
SINGLE、TV、Time-delay、Event-
delay、Edge、Pulse Width
Time Delay Range 100ns to 1.3ms
Events Delay Range 2 to 65000
Start Trigger Level
(For USER Mode)
±12V adjustable
Coupling AC，DC，LFrej，HFrej，Noise rej
