GDS-800 Series Digital Storage Oscilloscope Operation Manual

4

Use and Wear

CAUTION

• Do not exceed 300V

peak

into the channel BNC INPUTs.

• To avoid risk of fire hazard and electrical shock, a hazardous live voltage must

never be connected to the negative side (reference side) of the BNC measuring
terminals.

• Do not place any heavy object on the instrument.
• Avoid severe impacts or rough handling that could damage the oscilloscope.
• Use electrostatic discharge precautions while handling and making connections

to the oscilloscope.

• Do not place wires into the connectors of the oscilloscope, only mating connectors

and adapters.

• Do not block or obstruct cooling fan vent opening on side panels or on the rear

panel of unit.

1) Disassembly of the Instrument

• Do not disassemble the instrument; refer the instrument to a factory approved

service facility only.

2) AC Power Input

CAUTION

• AC input should be within the range of selected line voltage ±10%.

• Insure the correct fuse is installed prior to applying voltage for the first time -

100 V ~ 240 VAC input : T 2A / 250V
