GDS-800 Series Digital Storage Oscilloscope Operation Manual

49

z

Source: select channel 1 or channel 2 as subject signal input.

z

Violating Stop/

/Continue/

: Select the process after

subject is violating the compared templates.

Violating Stop: If subject signal is judged to be “No Good”, the “Go-No Go”

function will stop. The counts of violation will be recorded.

Violating

: If subject signal is judged to be “No Good”, the “Go-No

Go” function will stop and oscilloscope will beep once. The counts of

violation will be recorded.

Violating Continue: If subject signal is judged to be “No Good”, the “Go-No

Go” function will to be executed continually. The counts of violation will be

recorded.

Violating

: If subject signal is judged to be “No Good”, the “Go-No

Go” function will be executed continually and oscilloscope will beep once.

The counts of violation will be recorded.

Note: All the judgment condition are based on the setting of

No Go

When

/

. See next page for details.

z

Go- NoGo On/Off: Starts the “Go- No Go” function.

z

Ratio :: Display the counts of “Go-No Go” test and failure. Press F5 softkey

to reset the counts of ratio to zero.

Press any pushbutton to exit the “Go-No Go” function.
