GDS-800 Series Digital Storage Oscilloscope Operation Manual

51

z

Frequency: The adjustable frequency range for probe compensation signal

is from 1kHz to 100kHz, at 1kHz per step.

z

Duty Cycle: The adjustable duty cycle range for probe compensation signal

is from 5% to 95%, at 5% per step.

z

Default 1k: Press F4 soft key to output a 1k probe compensation signal.

NOTE: Always use 1k probe compensation signal to compensate the

probes, DO NOT use another frequencies except 1k to compensate the

probes.

z

Previous Menu: Press F5 softkey to previous menu.
