GDS-800 Series Digital Storage Oscilloscope Operation Manual

UTILITY: The utility menu provides abundant sub menus: Printer menu, Interface

menu,

(Beep), Language, self-cal menu, System Inform, Go-No Go

menu, and No Go When.

Printer Menu: If a printer is connected and properly configured, GDS-

820/GDS-840 series can print a hard copy of the LCD display. Press F1 softkey

again to select printer. This oscilloscope supports the following printers:

Type HP: Both Hewlett-Packard’s LaserJet laser printers and DeskJet inkjet

printers supported.

Press the pushbutton of HARDCOPY pushbutton to start printing from any time

after printer is properly configured.

Note: GDS-800 series oscilloscopes do not support any GDI printers.

Note: The USB of this oscilloscope is “DEVICE” only, this oscilloscope DO

NOT support any USB printers.

Note: Printer menu is available for GDS-806S/C and GDS-810S/C with

interface option, GDS-820S/C and GDS-840S/C.

Interface Menu: This oscilloscope can transfer data between the scope and

other instrument over the RS-232, USB, or GPIB interface. Press F1 softkey to

select the GPIB location.

Note: Interface menu is only available for GDS-806S/C and GDS-810S/C

with interface option; Interface menu is standard for GDS-820S/C and

GDS-840S/C.

Note: A total integrated of interface option for GDS-806S/C and GDS-

810S/C is including the USB port, Printer port, and Go/NoGo output BNC,

three kinds of output functions are in one option.

For RS232 setup

Type RS232: Select RS-232 communication port.

Baud rate: Transmission rate in characters per second. Transmission rate

selections are: 2400, 4800, 9600, 19200, and 38400 baud.
