GDS-800 Series Digital Storage Oscilloscope Operation Manual

11

AUTOSET

The “Autoset” function provides a stable, triggered display of any input signal (almost).

User can connect a signal to either the channel 1 or channel 2 input BNC connectors

and press AUTOSET button. Table 3-1 shows the defaults of “Autoset” function

Table 3-1: Defaults of “Autoset” function

Control

Modified by Autoset

Acquire

Sample

Acquire stop after

RUN/STOP button only

Display style

Vectors

Display format

YT

Horizontal position

Centered within the graticule windows

Horizontal Scale

As determined by the signal frequency

Trigger coupling

DC

Trigger level

Midpoint of data for the trigger source

Trigger position

Center

Trigger slope

Positive

Trigger source

Highest frequency if both channel available

Trigger type

Edge

Vertical bandwidth

Full

Vertical coupling

DC or AC (depend on the signal)

Vertical offset

0 V

Vertical scale

As determined by the signal level
