GETTING STARTED

9

AFG-125/225/125P/225P Overview

The AFG-125, AFG-225, AFG-125P and AFG-225P are arbitrary
function generator modules for use with the GDS-2000A series
DSOs. The options require the DS2-FH1 module extension bay to
secure the module to the DSO. This user manual will explain how
to become familiar with the arbitrary function generator modules.
The Getting Started chapter will introduce the modules with an
overview of the features and installation of the APP and
accompanying PC software. The Operation chapter will go over the
operation details.
Note1: The AFG-125/225/125P/225P are only supported with
GDS-2000A series DSOs with firmware version V1.19 or above
installed.
Note2: Throughout this manual AFG-125 will refer to both the
AFG-125 and the AFG-125P, unless stated otherwise. Similarly,
AFG-225 will refer to both the AFG-225 and AFG-225P, unless
stated otherwise.

Model Lineup

Model

AFG-125

AFG-125P AFG-225

AFG-225P

Frequency Range

1uHz-25MHz

Output Channels

1

1

2

2

Power Output

None

Yes

None

Yes
