OPERATION
69
Sets the rate of the ARB waveform*.
This will set the number of times
the ARB waveform will be output
each second.
Note
*The frequency setting is inversely proportional to the
Rate setting. The frequency and rate settings are also
directly affected by the length of the output ARB
waveform. See page 67 for setting the output length of
the ARB waveform.
**The amplitude and offset are linked. Together the
amplitude and offset cannot exceed 2.5Vpp (into
50Ω).
3. See page 29 to set the output
settings and turn the output on.
Page 29
