Creating/Editing a Preset ARB Waveform
Background The AFG-125/225 has a number of methods to
create and edit arbitrary waveforms. The ARB
waveforms can have a maximum of 4096 (0~4095)
points in length and 1023 (0±511) points in
amplitude.
Editing Methods Point/Line:
Creates a vertical line of a user-defined length and
amplitude.
Diagonal:
Creates a diagonal line of a user-defined length
and amplitude.
Scale:
Scales the full-scale of the ARB waveform.
Copy/Paste:
This method will copy and paste a user-defined
section of the ARB waveform.
Clear:
This will clear a user-defined section of the ARB
waveform.
Note: By default, any section of the ARB waveform
that is not edited will be set to 0Vpp. By default the
editing will automatically match the amplitude of
each point.
Steps 1. From the first level of the AFG
menu, press the Signal 1 Setup or
Signal 2 Setup key to select the
signal source.
