GW Instek AFG-100/200 Series User Manual User Manual
Page 39
OPERATION
39
The polarity can be set to Normal or
Inverted.
Polarity:
Normal, Inverted
Note
The marker mode can only be used for the ARB and
mod waveforms.
For the Sweep function, the marker output must be
turned on in the Sweep function menu. It cannot be
activated in the Sync Setup menu. See page 51 to turn
the marker option on.
