AFG-125/225 Series Options Manual
56
ARB
Loading a Preset ARB Waveform
Background The AFG-225 can load a number of different
waveforms as an arbitrary waveform file:
CH1~CH4, Ref1~Ref4, Wave1~Wave20, a
previously saved waveform (LSF and fast CSV
format*), a previously created ARB waveform or
one of the 66 preset ARB waveforms**. The preset
waveforms are categorized into Common, Math,
Window and Engineer waveforms, as shown in the
table below.
* See the DSO user manual for save file formats.
** See the appendix on page 72 for a full list and
description of the preset ARB waveforms.
Preset
waveforms Common:
Absatan, Abssin, Abssinehalf, Ampalt, Attalt,
Direven, Diriodd, Gauspuls, Havercos, Haversin,
Negramp, N_pulse, Rectpuls, Roundhaf, Sawtooth,
Sinetra, Sinever, Stair_dw, Stair_ud, Stair_up,
stepresp, trapezia, tripuls
Math:
Arccos, Arccot, Arccsc, Arcsec, Arcsin, Arcsinh,
Arctan, Arctanh, Cosh, Cot, Csc, Dlorentz,
Expofall, Exporise, Gauss, Ln, Lorentz, Sec, Sech,
Sinec, Sinh, Sqrt, Tan, Tanh, Xsquare
Window:
Barthwin, Bartlett, Blackman, Bohmwin, Chebyshe,
Flattwin, Hamming, Hann, Hanning, Kaiser,
Triang, Tukeywin
Engineer:
