Note
* The maximum length depends on the start address
setting.
The maximum length = 4096 – Start address.
3. Press Confirm to set the chosen
output section.
4. See page 29 to set the output
settings and turn the output on.
Page 29
Setting ARB Frequency, Rate, Amplitude & Offset
Background The rate, frequency, amplitude and
(amplitude)offset output parameters can also be
set.
Steps 1. From the ARB menu press more 1
of 2.
2. Select the parameters from the side menu:
Sets the frequency* of the ARB
waveform.
Sets the amplitude** of the
waveform:
1mVpp to 2.5Vpp (into 50Ω)
2mVpp to 5Vpp (open-circuit)
Sets the Offset** of the ARB
waveform:
±1.25Vpk ac +dc (into 50Ω)
±2.5Vpk ac +dc (Open circuit)
