Survey Pro Reference Manual
R-202
Accept : writes the results to raw data and returns you to the
Control Points screen.
Occupy Control Point Screen
Survey Control Points Control . or
Data Collection Control Control .
The Occupy Control Point screen is used to add geodetic coordinates
to a known project point. The most common use of this screen is to
measure control points for the localization solution. This screen is
also used by the Localization Calculator routine (Page R-218) for one
point localization setup.
Geodetic Coordinates
: displays the geodetic
coordinates measured at the current local
point.
Solution
Quality: displays the quality of the
current measurement: the solution type, the
number of satellites used, and the horizontal
and vertical precision computed by the
receiver. These values are explained with the
GPS Status screen (Page - R176)
Control Point
: is where you select if the
current point is to be used for Horizontal control
and/or Vertical control by tapping the appropriate checkboxes.
Session Time
: displays the total occupation time so far for this
measurement.
Count Status
: displays Measuring when you have current coordinates
from the receiver and the screen is updating with the latest
measurement. If you are using Epoch Averaging, Averaging is
displayed after you tap Accept while the number of epochs is
averaged in Survey Pro. Suspended is displayed if you are not
receiving valid data from the receiver.
GPS Status : opens the GPS Status screen (Page R-176).
Accept : adds the measured GPS coordinates to the point record in
the job file, and returns to the Control Points screen.
