<6. CALORIE / PARAMETER SETTING>

6-8

IM 11T3E1-01E

(1) Operation Level
Select a mode from the following four choices of the operation level. Each press of the [NO] key

cycles through the choices in the order shown below:

1. Display mode [DISP]

2. Semi-automatic calibration mode [SEM.CAL]

3. Manual calibration mode [MAN.CAL]

In the mode, “Density / Calorie Conversion Factor Setting Mode” is included in next page.

4. Valve operation mode [VALVE]

Press the [YES] key to enter the desired mode when it is indicated.

XXX

[ENT]

[NO]

[NO]

[NO]

[YES]

[YES]

[YES]

[YES]

[YES]

[YES]

Password is not selected in first condition

[MODE]

Semi-automatic calibration mode

Manual calibration mode

Valve operation mode

Measurement Mode

*PASSW

SEM.CAL

MAN.CAL

VALVE

See the process in Figure 9.3.

See the process in Figure 9.4.

See the process in Figure 9.1.

F0601.ai

(See "Figure 6.28 Setting of Password" on page 6-31.)

DISP

DISP mode

[YES]

[YES]

[NO]

You can abort the setting operation in any of the modes by pressing [MODE] key.

Doing this will return the analyzer to the measurement mode.

See the process in Figure 6.3.

Figure 6.1 Modes of Operation Level
