<7. HYDROGEN PURITY / PARAMETER SETTING>
7-26
IM 11T3E1-01E
CODE 41: Indication of Oscillation Frequency (Read-only)
This setting determines the F2 and F4 oscillation frequencies coefficients to be indicated.
(a) Indication of frequency F2 (kHz) [*F2.KHZ]:
indicated as X.XXXXX
(b) Indication of frequency F4 (kHz) [*F4.KHZ]:
indicated as X.XXXXX
(c) Indication of frequency ratio (kHz) [*F2/F4]:
indicated as X.XXXXX
[ENT]
41
*CODE
*SERVC
X.XXXXX
*F2.KHZ
X.XXXXX
*F4.KHZ
[ENT]
[ENT]
[YES]
F0722.ai
*
1
*
2
*
3
*1: See "Figure 7.4 Process at the Setting Level" on page 7-10.
*2: Enter the code number.
*3: By pressing the [ENT] key, the next indication is displayed.
This parameter does not accept the [ ] and [ ] key input.
[ENT]
X.XXXXX
*F2/F4
*
3
*
3
Figure 7.22 Indication of Oscillation Frequency
CODE 42: Indication of Software Version [*REV] (Read-only)
This setting allows the software version to be confirmed (indicated).
Indicated as X.XX
42
*CODE
*SERVC
X.XX
*REV
[ENT]
[ENT]
[YES]
F0723.ai
*
1
*
2
*
3
*1: See "Figure 7.4 Process at the Setting Level" on page 7-10.
*2: Enter the code number.
*3: Pressing the [ENT] key returns to the service level with the indication [*SERVC].
This parameter does not accept the [ ] and [ ] key input.
Figure 7.23 Indication of Software Version
