CODE 40: Indication of Calibration Coefficients (Read-only)
This setting determines the calibration coefficients to be indicated.
(a) Zero [*C_K_Z]: indicated as SX.XXXX
(b) Span [*C_K_S]: indicated as X.XXXX
[ENT]
40
*CODE
*SERVC
SX.XXXX
*C_K_Z
X.XXXX
*C_K_S
[ENT]
[ENT]
[YES]
F0624.ai
* 1
* 2
* 3
*1: See "Figure 6.4 Process at the Setting Level" on page 6-12.
*2: Enter the code number.
*3: By pressing the [ENT] key, the next indication is displayed.
This parameter does not accept the [ ] and [ ] key input.
Figure 6.24 Indication of Calibration Coefficients
CODE 41: Indication of Oscillation Frequency (Read-only)
This setting determines the F2 and F4 oscillation frequencies coefficients to be indicated.
(a) Indication of frequency F2 (kHz) [*F2.KHZ]: indicated as X.XXXXX
(b) Indication of frequency F4 (kHz) [*F4.KHZ]: indicated as X.XXXXX
(c) Indication of frequency ratio (kHz) [*F2/F4]: indicated as X.XXXXX
[ENT]
41
*CODE
*SERVC
X.XXXXX
*F2.KHZ
X.XXXXX
*F4.KHZ
[ENT]
[ENT]
[YES]
F0625.ai
* 1
* 2
* 3
*1: See "Figure 6.4 Process at the Setting Level" on page 6-12.
*2: Enter the code number.
*3: By pressing the [ENT] key, the next indication is displayed.
This parameter does not accept the [ ] and [ ] key input.
[ENT]
X.XXXXX
*F2/F4
* 3
* 3
Figure 6.25 Indication of Oscillation Frequency
