<2. Installation, Wiring and Piping>
2-9
IM 11T3E1-01E
● Panel Mounting
Figure 2.4 shows how to mount the converter on a panel.
139
+2
0
139
+2
0
Dimensions of cutout for panel mounting
Unit : mm
F0209.ai
Fixing screws (2 pcs)
Bracket
Converter
Insert the converter in
the panel cutout before
attaching the brackets.
Panel
Figure 2.8 Panel Mounting
(2) Mounting the GD402T, V, R Converter
F0210.ai
Figure 2.9 Mounting Explosion-proof Converter
A
Unit : mm (in.)
Weight : approx. 15 kg (33.1 pounds)
2 - M8 depth 16 (one on each side)
(Used to fix the pipe-mounting hardware)
4 - M8 depth 20
Side view from arrow A direction
Cable glands not included
A
B
D
E
C
F
Grounding terminal (M5)
Six wiring holes, G3/4 threaded (GD402R)
1/2 NPT threaded (GD402V, T)
Pipe-mounting hardware
Mounting pipe of JIS 50 A nominal size (Φ60.5)
Φ212 (8.3)
182 (7.2)
200 (7.9)
200 (7.9)
140 (5.5)
209 (8.2)
173 (6.8)
36 (1.4)
242 (9.5)
56
(2.2)
54
(2.1)
39
(1
.5
)
24 (0.9)
56
(2.2)
