<1. Specifications>
1-11
IM 11T3E1-01E
1.3.2 Pipe- and Wall-Mounting Hardware (Optional)
F0102.ai
Mounting pipe of JIS 50 A (60.5 mm in outer dia.)
3-Ø10 holes
23
(0.9)
135 (5.3)
70 (2.8)
100 (3.9)
185 (7.3)
13
(0.51)
178 (7)
100 (3.9)
224 (8.8)
200 (7.9)
35
(1.4)
195 (7.7)
15 (0.6)
max. 12
(panel thickness)
Optional
hardware
Optional
hardware
Optional
hardware
4 - M6 screws
4 - M6 screws
4 - M6 screws
Dimensions of panel cutout
188 (7.4)
100 (3.9)
174 (6.9)
200 (7.9)
50 (2)
• Hardware for Wall Mounting (Option code /U)
• Hardware for Panel Mounting (Option code /PA)
• Hardware for Pipe Mounting (Option code /U)
139 +1
0
+1 0 +1 0
Unit : mm (in.)
Weight : Approx. 3 kg
(5.47 ) +0.08
0
139
(5.47 )
