IM 11M13A01-02E 2-5
2. Specifications
Terminal Box Paint Color:
Case; Mint green (Munsell 5.6BG3.3/2.9)
Cover; Mint green (Munsell 5.6BG3.3/2.9)
Finish: Polyurethane corrosion-resistant coating
Gas Connection: Rc1/4 or 1/4 NPT
Wiring Connection:
ATEX; M20 by 1.5 mm or 1/2 NPT select one type (2 pieces)
FM; 1/2 NPT (2 pieces)
CSA; 1/2 NPT (2 pieces)
IECEx; M20 by 1.5 mm or 1/2 NPT select one type (2 pieces)
Installation: Flange mounting
Probe Mounting Angle: Horizontal to vertically downward.
Available Converter:ZR402G, AV550G
WARNING
The ZR22S must be used in conjunction with a ZR402G or AV550G. If used with a
converter other than a ZR402G or AV550G, the ZR22S does not operate as an
explosionproof equipment.
Weight:
Insertion length of 0.4 m: Approx. 13 kg (ANSI 150 4)
Insertion length of 1.0 m: Approx. 15 kg (ANSI 150 4)
Insertion length of 1.5 m: Approx. 17 kg (ANSI 150 4)
Insertion length of 2.0 m: Approx. 19 kg (ANSI 150 4)
Model and Suffix code
