Watlow EZ-ZONE ® RMA Module • 66 • Chapter 8 Appendix
As can be seen on the previous page the RMC module
is the only RM module that defaults to a populated
assembly structure. If it is desired to use the implicit
assembly for any of the other RM modules the as-
sembly structure must be built by the user. Their
are many software tools available to modify the as-
sembly structure and it is outside of the scope of this
document to describe how to use those. What can
be found in this document is the process to build the
assembly structure. If viewing this document elec-
tronically simply click on the link below to read the
section entitled " Modifying Implicit Assembly Mem-
bers ". Otherwise, turn back to the table of contents to
find the above named section.
Compact Class Assembly Structure
On the next four pages the 18 available members of
the Compact Class are displayed. While looking at
these illustrations keep in mind that each member of
the implicit assembly is 32-bits in length. To better
illustrate this information, each member was divided
in half where the most significant 16-bit words are
identified as MSW A and MSW B (see page headers)
and the least significant words are identified as the
LSW A and LSW B. In the event that these pages are
printed out and then mixed up, simply match up (left
to right) the pages MSW A and LSW A. Likewise,
match up MSW B to LSW B.
For further explanation as to what the Compact
Class assembly is, navigate to the RMA Communica-
tions Chapter and then to the section entitled " Com-
pact Implicit Assembly Class "
