Watlow EZ-ZONE ® RMA Module • 23 • Chapter 3 Operations Page
Access Module • Operations Page
Display
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
& Read/
Write
[2onE]
[ZonE] Backup
Zone
Current Zone indicates
which zone’s configuration
is being saved or restored or
was last saved or restored.
1 to 16 1 1276 0x8A
(138)
1 to 0x10
(16)
4
61 38004 uint
R
[b;sta]
[oPEr]
Backup Status Menu
[Stat]
[Stat] Backup
Status
Status indicates the status
of the current or most recent
backup function performed
on the corresponding zone.
None - means no backup or
restore action is running.
OK - indicates the zone
was successfully restored
or saved depending on the
operation.
No Memory - indicates
memory is full.
No Module - indicates that
a previous image for the
module had been saved but
while restoring the module
is no longer present.
No Image - indicates there
is no backed up image for a
module present on Standard
Bus.
Error - indicates that the
last action failed.
[none] None (61)
[``oH] OK (1644)
[No;m] No Memory (1637)
[no;m] No Module (1664)
[no;Ig] No Image (1665)
[`err] Error (28)
None 1280
[offset 6] 0x9A
(154)
1 to 0x18
(24)
1
94 54001 uint
R
Note: Some values will be rounded off to fit in the four-character display . Full values can
be read with other interfaces .
If there is only one instance of a menu, no submenus will appear .
R: Read
W: Write
E: EEPROM
S: User Set
