RMA / RME CIP Implicit Assembly Defaults
CIP Implicit Assembly Structure
Assembly
Members
Assembly
Class, Instance,
Attritbute
RM Module
Data Type
Parameter
Parameter
Class, Instance,
Attritbute
PLC
Data Type
1 0x77, 0x01, 0x01 DINT None specified 0x0, 0x00, 0x00 undefined
2 0x77, 0x01, 0x02 DINT None specified 0x0, 0x00, 0x00 undefined
3 0x77, 0x01, 0x03 DINT None specified 0x0, 0x00, 0x00 undefined
4 0x77, 0x01, 0x04 DINT None specified 0x0, 0x00, 0x00 undefined
5 0x77, 0x01, 0x05 DINT None specified 0x0, 0x00, 0x00 undefined
6 0x77, 0x01, 0x06 DINT None specified 0x0, 0x00, 0x00 undefined
7 0x77, 0x01, 0x07 DINT None specified 0x0, 0x00, 0x00 undefined
8 0x77, 0x01, 0x08 DINT None specified 0x0, 0x00, 0x00 undefined
9 0x77, 0x01, 0x09 DINT None specified 0x0, 0x00, 0x00 undefined
10 0x77, 0x01, 0x0A DINT None specified 0x0, 0x00, 0x00 undefined
11 0x77, 0x01, 0x0B DINT None specified 0x0, 0x00, 0x00 undefined
12 0x77, 0x01, 0x0C DINT None specified 0x0, 0x00, 0x00 undefined
13 0x77, 0x01, 0x0D DINT None specified 0x0, 0x00, 0x00 undefined
14 0x77, 0x01, 0x0E DINT None specified 0x0, 0x00, 0x00 undefined
15 0x77, 0x01, 0x0F DINT None specified 0x0, 0x00, 0x00 undefined
16 0x77, 0x01, 0x10 DINT None specified 0x0, 0x00, 0x00 undefined
17 0x77, 0x01, 0x11 DINT None specified 0x0, 0x00, 0x00 undefined
18 0x77, 0x01, 0x12 DINT None specified 0x0, 0x00, 0x00 undefined
19 0x77, 0x01, 0x13 DINT None specified 0x0, 0x00, 0x00 undefined
20 0x77, 0x01, 0x14 DINT None specified 0x0, 0x00, 0x00 undefined
Assembly
Members
Assembly
Class, Instance,
Attritbute
RM Module
Data Type
Parameter
Parameter
Class, Instance,
Attritbute
PLC
Data Type
1 Cannot be changed Binary Device Status none DINT
2 0x77, 0x02, 0x01 DINT None specified 0x0, 0x00, 0x00 undefined
3 0x77, 0x02, 0x02 DINT None specified 0x0, 0x00, 0x00 undefined
4 0x77, 0x02, 0x03 DINT None specified 0x0, 0x00, 0x00 undefined
5 0x77, 0x02, 0x04 DINT None specified 0x0, 0x00, 0x00 undefined
6 0x77, 0x02, 0x05 DINT None specified 0x0, 0x00, 0x00 undefined
7 0x77, 0x02, 0x06 DINT None specified 0x0, 0x00, 0x00 undefined
8 0x77, 0x02, 0x07 DINT None specified 0x0, 0x00, 0x00 undefined
9 0x77, 0x02, 0x08 DINT None specified 0x0, 0x00, 0x00 undefined
10 0x77, 0x02, 0x09 DINT None specified 0x0, 0x00, 0x00 undefined
11 0x77, 0x02, 0x0A DINT None specified 0x0, 0x00, 0x00 undefined
12 0x77, 0x02, 0x0B DINT None specified 0x0, 0x00, 0x00 undefined
13 0x77, 0x02, 0x0C DINT None specified 0x0, 0x00, 0x00 undefined
14 0x77, 0x02, 0x0D DINT None specified 0x0, 0x00, 0x00 undefined
15 0x77, 0x02, 0x0E DINT None specified 0x0, 0x00, 0x00 undefined
16 0x77, 0x02, 0x0F DINT None specified 0x0, 0x00, 0x00 undefined
17 0x77, 0x02, 0x10 DINT None specified 0x0, 0x00, 0x00 undefined
18 0x77, 0x02, 0x11 DINT None specified 0x0, 0x00, 0x00 undefined
19 0x77, 0x02, 0x12 DINT None specified 0x0, 0x00, 0x00 undefined
20 0x77, 0x02, 0x13 DINT None specified 0x0, 0x00, 0x00 undefined
21 0x77, 0x02, 0x14 DINT None specified 0x0, 0x00, 0x00 undefined
CIP Implicit Assembly
Originator (Master) to Target ( RMA / RME )
CIP Implicit Assembly
Target ( RMA / RME ) to Originator (Master)
