Watlow EZ-ZONE ® RMA Module • 35 • Chapter 5 Factory Page
Chapter 5: Factory Pages
5
Access Module Factory Page Parameters
Note:
Some of these menus and parameters may not appear, depending on the controller's options. See model number
information in the Appendix for more information. If there is only one instance of a menu, no submenus will ap-
pear.
Note:
Some of the listed parameters may not be visible. Parameter visibility is dependent upon controller part number.
To navigate to the Factory Page using the RUI, follow
the steps below:
1. From the Home Page, press and hold both the Ad-
vance ‰ and Infinity ˆ keys for six seconds.
2. Press the Up ¿ or Down ¯ key to view available
menus.
3. Press the Advance Key ‰ to enter the menu of
choice.
4. If a submenu exists (more than one instance), press
the Up ¿ or Down ¯ key to select and then press
the Advance Key ‰ to enter.
5. Press the Up ¿ or Down ¯ key to move through
available menu prompts.
6. Press the Infinity Key ˆ to move backwards
through the levels: parameter to submenu; submenu
to menu; menu to Home Page.
7. Press and hold the Infinity Key ˆ for two seconds to
return to the Home Page.
On the following pages, top level menus are identified
with a yellow background color.
[`LoC]
[FCty]
Security Setting Menu
[LoC;o] Operations Page
[pas;e] Password Enable
[RloC]
Read Lock
[SLoC] Write Security
[loC;l] Locked Access Level
[roll] Rolling Password
[pas;u] User Password
[pas;a] Administrator Password
[ULoC]
[FCty]
Security Setting Menu
[CoDE] Public Key
[pass] Password
[diAg]
[FCty]
Diagnostics Menu
[`s;id] Software ID
[`s;rl] Software Release Version
[`s;pr] Software Protoype Ver-
sion
[s;bld] Software Build Number
[``Sn]
Serial Number
[dAtE] Date of Manufacture
[ip;aC] Actual IP Addressing
Mode
[ip;a1] IP Actual Address Part 1
[ip;a2] IP Actual Address Part 2
[ip;a3] IP Actual Address Part 3
[ip;a4] IP Actual Address Part 4
