Watlow EZ-ZONE ® RMA Module • 24 • Chapter 4 Setup Page
Chapter 4: Setup Pages
4
Access Module Setup Page Parameters
To navigate to the Setup Page using the RUI, follow
the steps below:
1. From the Home Page, press both the Up ¿ and
Down ¯ keys for six seconds. [``Ai] will appear
in the upper display and [`Set] will appear in the
lower display.
2. Press the Up ¿ or Down ¯ key to view available
menus.
3. Press the Advance Key ‰ to enter the menu of
choice.
4. If a submenu exists (more than one instance), press
the Up ¿ or Down ¯ key to select and then press
the Advance Key ‰ to enter.
5. Press the Up ¿ or Down ¯ key to move through
available menu prompts.
6. Press the Infinity Key ˆ to move backwards
through the levels: parameter to submenu; submenu
to menu; menu to Home Page.
7. Press and hold the Infinity Key ˆ for two seconds to
return to the Home Page.
On the following pages, top level menus are identified
with a yellow background color.
Note:
Some of these menus and parameters may not appear, depending on the controller's options. See model number
information in the Appendix for more information. If there is only one instance of a menu, no submenus will ap-
pear.
Note:
Some of the listed parameters may not be visible. Parameter visibility is dependent upon controller part number.
[gLbL]
[`Set]
Global Menu
[d;prs] Display Pairs
[Usr;s] User Settings Save
[Usr;r] User Settings Restore
[COM]
[`Set]
Communications Menu
[[Ad;M] Modbus Address
[bAUd] Baud Rate
[`PAr] Parity
[M;hL] Modbus Word Order
[iP;M] IP Address Mode
[iP;F1] IP Fixed Address Part 1
[iP;F2] IP Fixed Address Part 2
[iP;F3] IP Fixed Address Part 3
[iP;F4] IP Fixed Address Part 4
[iP;S1] IP Fixed Subnet Part 1
[iP;S2] IP Fixed Subnet Part 2
[iP;S3] IP Fixed Subnet Part 3
[iP;S4] IP Fixed Subnet Part 4
[iP;g1] Fixed IP Gateway Part 1
[iP;g2] Fixed IP Gateway Part 2
[iP;g3] Fixed IP Gateway Part 3
[iP;g4] Fixed IP Gateway Part 4
[Mb;E] Modbus TCP Enable
[EiP;E] EtherNet/IP™ Enable
[`Ad;d] DeviceNet™ Node Address
[BAUd] Baud Rate DeviceNet™
[`FC;E] DeviceNet™ Quick
Connect Enable
[P;add] Profibus Address
[A;loC] Profibus Address Lock
[stat] Profibus Status
[`C_f] Display Units
[`nu;s] Non-volatile Save
[gtW]
[`Set]
Local Remote Gateway Menu
[```1] to [``17]
[gtW] Local Remote Gateway (1 to
17)
[du;En] Device Enabled
[du;St] Device Status
[M;oF] Modbus Address Offset
[`oSt] CIP Instance Offset
[ao;nb] CIP Implicit Assembly
Output Member Quantity
[ai;nb] CIP Implicit Assembly
Input Member Quantity
[`s;of] Profibus Slot Offset
[rtC]
[`Set]
Real Time Clock Menu
[hoUr] Hours
[Min] Minutes
[Mon] Month
[dAtE] Date
[YEAr] Year
[doW] Day of Week
[t;For] Time Format
[d;For] Date Format
[`Pro]
[`Set]
Profile Menu
[Poti] Power Off Time
[dLog]
[`Set]
Data Logging Menu
[PErd] Period
[f;act] Full Action
[Sfn;A] Source Function A
[`Si;A Source Instance A
[`S2;A] Source Zone A
[Lg;pt]
[`Set]
Log Point Menu
[```1] to [`200]
[Lg;pt] Log Point (1 to 200)
[SFn;A] Source Function A
[`Si;A] Source Instance A
[`S2;A] Source Zone A
[`dEC] Display Precision
[bCUP]
[`Set]
Backup Menu
[SAuE] Save
[rEST] Restore
[`uAr]
[`Set]
Variable Menu
[type] Data Type
[Unit] Units
[`dig]
Digital
[AnLg] Analog
