Watlow EZ-ZONE ® RMA Module • 31 • Chapter 4 Setup Page
Access Module • Setup Page
Display
Parameter name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Param-
eter
ID
Data
Type
& Read/
Write
[dLog]
[`SEt]
Data Logging Menu
[PErd]
[PErd] Data Logging
Period
Use Period to set the time
in seconds between when
records are entered in the
data log.
1 to 3,600 10 1450 0x89
(137)
1
1
49 37001 uint
RWES
[f;act]
[F.Act] Data Logging
Full Action
Use Full Action to select
whether the data logging
function should Stop or
begin to Overwrite old data
once the data log memory
is full. .
[stop] Stop (1638)
[ourt] Overwrite (1639)
Stop 1454 0x89
(137)
1
3
51 37003 uint
RWES
[Sfn;a]
[SFn.A] Data Logging
Source Function A
Select a function with a
digital output that will be
used to start and stop data
logging..
[none] None (61)
[ALM] Alarm (6)
[`CPE] Compare (230)
[`Ctr] Counter (231)
[`dio] Digital I/O (1142)
[Ent;A] Profile Event Out
A (233)
[Ent;b] Profile Event Out
B (234)
[Ent;C] Profile Event Out
C (235)
[Ent;d] Profile Event Out
D (236)
[Ent;E] Profile Event Out
E (247)
[Ent;F] Profile Event Out
F (248)
[Ent;g] Profile Event Out
G (249)
[Ent;h] Profile Event Out
H (250)
[`FUn] Function Key
(1001)
[`LgC] Logic (239)
[tMr] Timer (244)
[`uAr] Variable (245)
Variable 1460 0x89
(137)
1
6
- - - - 37006 uint
RWES
[`si;A]
[ Si.A] Data Logging
Source Instance A
Set the instance of the func-
tion selected above.
1 to 24 1 1462 0x89
(137)
1
7
- - - - 37007 uint
RWES
[`s2;A]
[ SZ.A] Data Logging
Source Zone A
Set the zone of the function
selected above. Set Source
Zone A to zero to select a
source in the Access Module
such as Variable 1.
0 to 16 0 1464 0x89
(137)
1
8
- - - - 37008 uint
RWES
Note: Some values will be rounded off to fit in the four-character display . Full values can be
read with other interfaces .
If there is only one instance of a menu, no submenus will appear .
R: Read
W: Write
E: EEPROM
S: User Set
