Chapter 8 Appendix
Chapter 8: Appendix
Modbus - User Programmable Memory Blocks
Assembly Definition Address and Assembly Working Addresses
Definition Addresses Working Addresses
Definition Addresses Working Addresses
40 & 41
200 & 201
120 & 121
280 & 281
42 & 43
202 & 203
122 & 123
282 & 283
44 & 45
204 & 205
124 & 125
284 & 285
46 & 47
206 & 207
126 & 127
286 & 287
48 & 49
208 & 209
128 & 129
288 & 289
50 & 51
210 & 211
130 & 131
290 & 291
52 & 53
212 & 213
132 & 133
292 & 293
54 & 55
214 & 215
134 & 135
294 & 295
56 & 57
216 & 217
136 & 137
296 & 297
58 & 59
218 & 219
138 & 139
296 & 299
60 & 61
220 & 221
140 & 141
300 & 301
62 & 63
222 & 223
142 & 143
302 & 303
64 & 65
224 & 225
144 & 145
304 & 305
66 & 67
226 & 227
146 & 147
306 & 307
68 & 69
228 & 229
148 & 149
308 & 309
70 & 71
230 & 231
150 & 151
310 & 311
72 & 73
232 & 233
152 & 153
312 & 313
74 & 75
234 & 235
154 & 155
314 & 315
76 & 77
236 & 237
156 & 157
316 & 317
78 & 79
238 & 239
158 & 159
318 & 319
80 & 81
240 & 241
160 & 161
320 & 321
82 & 83
242 & 243
162 & 163
322 & 323
84 & 85
244 & 245
164 & 165
324 & 325
86 & 87
246 & 247
166 & 167
326 & 327
88 & 89
248 & 249
168 & 169
328 & 329
90 & 91
250 & 251
170 & 171
330 & 331
92 & 93
252 & 253
172 & 173
332 & 333
94 & 95
254 & 255
174 & 175
334 & 335
96 & 97
256 & 257
176 & 177
336 & 337
98 & 99
256 & 259
178 & 179
338 & 339
100 & 101
260 & 261
180 & 181
340 & 341
102 & 103
262 & 263
182 & 183
342 & 343
104 & 105
264 & 265
184 & 185
344 & 345
106 & 107
266 & 267
186 & 187
346 & 347
108 & 109
268 & 269
188 & 189
348 & 349
110 & 111
270 & 271
190 & 191
350 & 351
112 & 113
272 & 273
192 & 193
352 & 353
114 & 115
274 & 275
194 & 195
354 & 355
116 & 117
276 & 277
196 & 197
356 & 357
118 & 119
278 & 279
198 & 199
358 & 359
Note:
Notice that in the Modbus tables that follow the first 40 members have predefined definitions from the factory.
These members reflect the assembly of the RMC module only. All other RM module assemblies are undefined as
delivered from the factory; if the undefined members are to be used, they must be configured by the user
