HMC7000 Series I/O Module Guide

Phone: 425/745-3229 • Fax: 425/745-3429 • Email: [email protected] • www.maplesystems.com

.

1010-1043

Page 66 of 85

Rev. 02, 11/08/2013

Reference the table below when configuring each Input Configuration Register (MWnn00-MWnn03):

Input Channel

Signal Type

Value

Voltage, 0 to 10V

1

Voltage, 0 to 5V

6

Voltage, -10 to +10V

18

Voltage, 0 to 50mV

5

Voltage, 0 to 100mV

4

Current, 4 to 20mA

2

Current, 0 to 20mA

3

RTD, PT100, alpha1

1

7

RTD, PT100, alpha2

1

8

RTD, PT1000

9

Thermocouple, Type J

2

14

Thermocouple, Type K

2

15

Notes:

1. alpha1= 0.00385 Ω/Ω/°C, alpha2=0.003926 Ω/Ω/°C
2. 15-minute module warm-up time recommended


Reference the table below when configuring each Output Configuration Register (MWnn04-MWnn05):

Output Channel

Signal Type

Value

Voltage, 0 to 10V

2

Voltage, 0 to 5V

1

Current, 4 to 20mA

5

Current, 0 to 20mA

6
