HMC7000 Series I/O Module Guide
Phone: 425/745-3229 • Fax: 425/745-3429 • Email: [email protected] • www.maplesystems.com .
1010-1043 Page 65 of 85 Rev. 02, 11/08/2013
Configuration:
Use MAPware-7000 to assign input (XW) and configuration (MW) memory addresses to the module.
These addresses are created according to the slot location of the module, where nn refers to the slot
number (ex. 01…05):
Register Description Access
XWnn00 Input Channel 1 Data Read Only
XWnn01 Input Channel 2 Data Read Only
XWnn02 Input Channel 3 Data Read Only
XWnn03 Input Channel 4 Data Read Only
YWnn00 Output Channel 1 Data Read/Write
XWnn01 Output Channel 2 Data Read/Write
MWnn00 Input Channel 1 Configuration Register Read/Write
MWnn01 Input Channel 2 Configuration Register Read/Write
MWnn02 Input Channel 3 Configuration Register Read/Write
MWnn03 Input Channel 1 Configuration Register Read/Write
MWnn04 Output Channel 1 Configuration Register Read/Write
MWnn05 Output Channel 2 Configuration Register Read/Write
MWnn10 Analog Input Error Register Read/Write
Analog Input Error Register Bit Assignment
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
Un
u
sed
Un
u
sed
Un
u
sed
Un
u
sed
C
h
4
Op
en
T
h
er
m
o
co
u
p
le
C
h
4
Op
en
R
T
D
Un
u
sed
C
h
3
Op
en
T
h
er
m
o
co
u
p
le
C
h
3
Op
en
R
T
D
Un
u
sed
C
h
2
Op
en
T
h
er
m
o
co
u
p
le
C
h
2
Op
en
R
T
D
Un
u
sed
Ch
1
Op
en
T
h
er
m
o
co
u
p
le
C
h
1
Op
en
R
T
D
Un
u
sed
