HMC7000 Series I/O Module Guide
Phone: 425/745-3229 • Fax: 425/745-3429 • Email: [email protected] • www.maplesystems.com
.
1010-1043
Page 9 of 85
Rev. 02, 11/08/2013
Reference the table below when configuring each Input Configuration Register (MWnn00-MWnn07):
Input Channel
Signal Type
Value
Voltage (0 - 10V)
1
Voltage (-10 to +10V)
2
