HMC7000 Series I/O Module Guide
Maple Systems Inc., 808 134th Street SW, Suite 120, Everett, WA 98204-7333 • www.maplesystems.com
1010-1043
Page 1 of 35
Rev. 02, 11/08/2013
Introduction
The HMC7000 Series (except for the HMC7030A-L) support I/O expansion modules. These
modules provide digital and/or analog I/O (inputs and outputs) for an electrical control system.
All of the I/O Modules are CE and UL Certified. The following I/O Modules are available:
I/O Module Part No. Description
16 Digital Inputs (sinking or sourcing)
4 Programmable Analog Inputs
8 Programmable Analog Voltage Inputs
8 Programmable Analog Current Inputs
12 Relay Outputs
16 Digital Outputs (Sinking 0.5A)
16 Digital Outputs (Sourcing 0.5A)
8 Bidirectional Digital Inputs, 8 Digital Outputs (Sinking 0.5A)
8 Bidirectional Digital Inputs, 8 Digital Outputs (Sourcing 0.5A)
2 Programmable Analog Inputs, and 2 Programmable Analog Outputs
8 Bidirectional Digital Inputs (4 high speed), 8 Digital Outputs
(Sinking 0.5A)
8 Bidirectional Digital Inputs (4 high speed), 8 Digital Outputs
(Sourcing 0.5A)
8 Bidirectional Digital Inputs (4 high speed), 8 Digital Outputs
(2 PWM, Sinking 0.5A), 6 Relay
8 Bidirectional Digital Inputs (4 high speed), 8 Digital Outputs
(2 PWM, Sourcing 0.5A), 6 Relay
4 Programmable Analog Inputs, 2 Programmable Analog Outputs
Some HMC7000 Series models have built in I/O. These units are also CE and UL Certified.
HMC Part No.
Description
3” LCD, 18 membrane-style keys, 1 serial port, 1 USB slave port,
12 digital inputs and 8 digital outputs built-in
