HMC7000 Series I/O Module Guide
Phone: 425/745-3229 • Fax: 425/745-3429 • Email: [email protected] • www.maplesystems.com .
1010-1043 Page 5 of 85 Rev. 02, 11/08/2013
HMC7-MI-02 (4 Input Analog Module)
This module is an analog input module for the HMC7000
Series models. It has four analog inputs, which can measure
0-10V, -10 to +10V, 0-20mA, and 4-20mA signals.
Specifications:
Power 3.9 VDC from HMC7000 base
Approvals CE, UL
Analog Inputs 4 Inputs (0-10V, -10 to +10V, 0-20mA, and 4-20mA)
Resolution 12 bit
Connection method Removable terminals (3.81 mm pitch)
Voltage Mode
Input range -10V to +10V, 0 - 10V
Value of LSB:
For 0-10V: 2.44mV
For +/-10V: 4.88mV
Input Impedance
200KΩ
Accuracy
At 25°C: 0.1% of full scale
Overall Accuracy (-25°C to 55°C) 0.3% of full scale
Frequency Limit (-3db) 3.5KHz
Behavior upon sensor failure Input goes to 0, as if no input is connected
Current Mode
Input Range 4mA-20mA, 0mA-20mA
Value of LSB 3.906 μA
Input Impedance 120Ω
Accuracy
At 25°C: 0.2% of full scale
Overall Accuracy (-25°C to 55°C) 0.8% of full scale
General
Operating Temperature 0 to 55°C
Operating Humidity 10% to 90% (non condensing)
Mechanical Dimension (LxWxH) 3.11x1.18x1.42 inches [79x30x36mm]
Input Power Supply
Input Voltage 24VDC
Input Current 50mA
