HMC7000 Series I/O Module Guide
Phone: 425/745-3229 • Fax: 425/745-3429 • Email: [email protected] • www.maplesystems.com .
1010-1043 Page 28 of 85 Rev. 02, 11/08/2013
Current Mode
Output Range 4mA-20mA
Value of LSB 3.9 μA
Output Load Maximum 500 Ohm
Accuracy
At 25°C: 0.2% of full scale
Overall Accuracy (-25°C to 55°C) 0.8% of full scale
Current Mode
Output Range 0mA-20mA
Value of LSB 4.8 µA
Output Load Maximum 500 Ohm
Accuracy
At 25°C: 0.13% of full scale
Overall Accuracy (-25°C to 55°C) +10ppm/°C of full scale
General
Operating Temperature 0 to 55°C
Operating Humidity 10% to 90% (non condensing)
Mechanical Dimension (LxWxH) 3.11x1.18x1.42 inches [79x30x36mm]
Input Power Supply
Input Voltage 24VDC
Input Current 50mA
