background image

HMC7000 Series I/O Module Guide

Phone: 425/745-3229 • Fax: 425/745-3429 • Email: [email protected] • www.maplesystems.com

.

1010-1043

Page 44 of 85

Rev. 02, 11/08/2013

Pulse/Direction

Function

Register

Description

Output, PWM Pulse

Y2

Physical Output

Output, PWM Direction

Y4

Configuration Register

MWnn24

Value = 7 for this mode

Frequency Setting Register

MWnn25
MWnn26

Range = -10000 to -1;
1 to 10000

Output Enable Flag

MWnn36_0

Enabled when ON

Frequency Setting Error Flag

MWnn29_3

ON = error (resets automatically)

Fixed Pulse Mode

Function

Register

Description

Output, PWM Pulse

Y2

Physical Output

Configuration Register

MWnn24

Value = 9 for this mode

Minimum Frequency Register

MWnn25
MWnn26

Range = 1 to 10000

Maximum Frequency Register

MWnn27
MWnn28

Range = 1 to 10000

Acceleration Time Register

MWnn37

Range: 0 to 32767

Deceleration Time Register

MWnn39

Range: 0 to 32767

Total Pulses Register

MWnn41
MWnn42

0 to 2147483647

Elapsed Pulses Register

MWnn45
MWnn46

0 to 2147483647

Output Enable Flag

MWnn36_0

Enabled when ON

Frequency Setting Error Flag

MWnn29_3

ON = error (resets automatically)

Acceleration Time Error Flag

MWnn29_4

ON = error

Deceleration Time Error Flag

MWnn29_5

ON = error

Total Pulses Setting Error Flag

MWnn29_6

ON = error

Total Pulses Reached

MWnn49_0

ON when Total Pulses have been
sent
