HMC7000 Series I/O Module Guide
Phone: 425/745-3229 • Fax: 425/745-3429 • Email: [email protected] • www.maplesystems.com .
1010-1043 Page 30 of 85 Rev. 02, 11/08/2013
Reference the table below when configuring each Input/Output Configuration Register (MWnn00-
MWnn03)
Input Channel
Signal Type
Value
mA (4-20mA) 0
Voltage (0-10V) 1
Voltage (-10 to +10V) 2
mA (0-20mA) 3
Output Channel
Signal Type
Value
mA (4-20mA) 0
Voltage (0-10V) 1
Reserved 2
mA (0-20mA) 3
