Output zero and attenuation accuracy can be measured in the field and verified with any
platform/cable assembly.
If the probe package includes multiple probe interconnect leads, the best practice is to complete the
entire procedure for each probe interconnect lead. If more than one interconnect lead is being
verified, copy and fill out a separate test record for each platform/cable assembly, amplifier module,
and interconnect lead.
If the probe package includes probe interconnect leads that are not serialized to the amplifier
module and platform/cable assembly, then performance may not be verifiable.
NOTE: It is recommended that the Functional Check be performed prior to the Performance
Verification Procedure to assure all other non-warranted functions perform as specified. See Quick
Functional Check (on page 68) for more information.
Required Test Equipment
The following table lists the test equipment and accessories, or their equivalents, required for
performance verification of the WaveLink Series of High Bandwidth Differential Probes.
The procedure has been developed to minimize the number of parameters requiring calibration in
the test instrumentation. Only the parameters listed in boldface in the Minimum Requirements
column must be calibrated to the accuracy indicated.
Because the input and output connector types may vary on different brands and models of test
instruments, additional adapters or cables may be required.
Description Minimum Requirements Test Equipment Examples
Oscilloscope,
High Impedance
200 mV/div - 2 V/div scale factor 1
MΩ input impedance ProBus
interface
Teledyne LeCroy: WaveMaster 8 Zi/Zi-A
Series, or any Teledyne LeCroy
oscilloscope with ProBus compatible 1
MΩ input
Digital Multimeter AC: 0.2% accuracy to measure
200 mV and 2 V
rms
@ 1 kHz
6½ digit resolution
Agilent Technologies: 34401A
Fluke: 8842A-09
Keithley: 2001
Oscillator/Function Generator Sine Wave output, adjustable from
500 mV to 4 Vp-p
(357 mV to 2.83 V
rms
) at 70 Hz
Stanford Research: Model DS340
Agilent Technologies: 33120A
Leader: LAG-120B
Calibration Fixture 1 See Preliminary Procedure Teledyne LeCroy: ProLink-CF01
Calibration Fixture 2 See Preliminary Procedure Teledyne LeCroy: LPA-2.92
Terminator, Precision, BNC 50 Ω ± 0.05% Teledyne LeCroy: TERM-CF01
Probe Deskew Fixture 3 Teledyne LeCroy: PCF-200
