4. X11CA Software Operation
Hardware Control-© 2003 Ronan Engineering 53
4.11.1 Testing A Single Module
1) Before you start testing, makes sure that the logical module cell to be tested
displays ‘Run’ message.
2) Click in a logical module cell on the Main window.
3) Click on the T button in the PB area.
The test result depends on the test type set on the System Setup window.
Lamp Test Only Type
Pressing the T button on the Main window simulates active the Field Contact
inputs of the selected physical module. All the lamplights of the selected module
will light up.
Releasing the button will turn off all the lamplights.
Operational Test Type
Pressing the T button will light up all the lamps of the selected module. The
operational test result depends on the sequence type of the selected channels. If
any signal is set for the Global Function keys, you can press the GF1 or GF2 key
to test it.
For the sequence process, refer to the sequence charts on the CD.
4.11.2 Testing All Modules At Once
1) Before you start testing, makes sure that the logical module cells to be tested
display ‘Run’ messages.
2) Click on the T button in the PB area.
The test result depends on the test type set on the System Setup window.
Lamp Test Only Type
Pressing the T button on the Main window simulates activating the Field Contact
inputs of the physical modules whose logical modules are in Run mode. All the
lamplights of the running modules will light up.
Releasing the button will turn off all the lamplights.
Operational Test Type
